Name: Hwashi Cap Cover Automatic Spot Welding Machine with Multi Welding Station
Brand: Guangdong Hwashi Technology inc.
SKU: Wl-mf-50K
Price: 157,805.00 USD
Availability: InStock

Huis > producten > De Machine van het vleklassen >

Hwashi Cap Cover Automatic Spot Welding Machine with Multi Welding Station

automatic spot welding machine

multi welding station machine

cap cover spot welder

Plaats van herkomst:

China

Merknaam:

HWASHI

Certificering:

CE/CCC/ISO

Modelnummer:

Wl-mf-50K

Contacteer ons

Verzoek om een Citaat

Productdetails

Productnaam:

Hwashi Cap Cover Automatische pleklassen met meerdere lasstations

Applicatie:

Laskappen dekking / schelp

Maat:

1900x800x1600 mm

Leven in dienst:

8-10 jaar

Gewicht:

600 kg

Garantie:

12 maanden

Standaard:

CE/CCC/ISO

Betaling & het Verschepen Termijnen

Min. bestelaantal

1 set

Prijs

Onderhandelbaar

Verpakking Details

Zeewaardig houten pakket

Levertijd

7-30 werkdagen nadat uw betaling is ontvangen

Betalingscondities

L/C, , T/T

Levering vermogen

50 sets per maand

Verwante producten

Video

HWASHI Wire Diameter 2-8mm Automatic ring making butt welding machine Circle Ring Bar Pneumatic Resistance Butt Welding Machine

Krijg Beste Prijs

Video

Hwashi Customizable AC Pulse Spot Welding Machine for Different Welding Requirements in Hardware Industry

Krijg Beste Prijs

Video

HWASHI Wire Frame T Butt Welding Machine

Krijg Beste Prijs

Video

Battery Spot Welder Resistance Welding Machine Capacitive Energy Spot Welder Stainless Steel Spot Weld Machine Price

Krijg Beste Prijs

Contacteer ons

+8613380655800

marketing@hwashi.com

Contact nu

Productomschrijving

Hwashi Cap Cover Automatic Spot Welding Machine with Multi Welding Station

Hwashi Cap Cover Automatic Spot Welding Machine with Multi Welding Station 0

Product description

HWASHI Full Automatic Rotary Table Spot Welding Machine for Nut, Capacitor Welding is designed as automatic welding, automatic rotating and automatic discharging. The machine is of 8 welding positions, so it can achieve cycle working and continuous welding. Moreover, medium frequency inverter power source is adopted with features of high power factor, electricity and energy saving, and it can achieve stable and reliable welding spots. Only need to change the fixtures (welding moulds) then the machine can achieve welding different products. The present design could help you weld product with different dimensions. The main welding part of Multi-station CNC Automatic Rotary Spot Welding Machine is equipped with automatic rotating device. The operator only needs to put the work piece onto the rotary device. He can put 8 work pieces at most for one time. Then start “welding”, the main welding body will conduct welding. After welding the No. 1 work piece, the rotating device will rotate, then the No.2 work piece will be moved to the welding position, cycle process will continue. In the meantime, the welded work piece will be discharged automatically in turn and the operator could keep putting new work piece onto the certain position. In such design, the machine is of fast speed and high efficiency.

Hwashi Cap Cover Automatic Spot Welding Machine with Multi Welding Station 1

Multi Station Special Designed Fixture

We will design the fixture according to your actual product.

Automatic Vibration Feeding Plate

It will feed the small parts to the fixture automatically.

And the machine will do assembly and welding automatically.

Hwashi Cap Cover Automatic Spot Welding Machine with Multi Welding Station 3

Automatic Loading and Unloading Mechanical Arm Final Product Quality

Technical Parameters of Full Automatic Rotary Table Spot Welding Machine
1	Input Voltage	380V three-phase
2	Input Current	150A
3	Output Voltage	DC11.6V
4	Max Short Circuit Current	32000A
5	Welding Models	32 types
6	Rotary Table Diameter	800mm
7	Rotary Table Material Positions	6-8 positions
8	Rotary Table Rotating Speed	0.5m/sec

Hwashi Cap Cover Automatic Spot Welding Machine with Multi Welding Station 5
